Nokia Asha 205 Headset Audio Solution Handsfree Ways
Nokia 205 Handsfree Solution Jumper Problem Ways

The solution below shows the location of particular components that holds the headset audio signals like the external microphone and earpiece.
If ever tried to fix this problem , you may need to check first if the headset is properly plug-in and ensure that it is working or already tried replacing a good working one. If this happens you may then also check the AV plug connector if the terminal soldered if damaged or already lifted from the PCB board.
The solution above shows the connection of the headset AV jack connector terminal pads which is useful in high level troubleshooting procedures. It also includes the filter ICs connection for jumper remedies.

Hints in troubleshooting the headset problem on Nokia Asha 205:
1. Check, clean or replace the headset AV jack connector.
2. Clean the AV jack connector terminal contact pads.
3. Trace the each particular connection like the microphone or the earpiece.
4. Check, replace the connected components on a particular connections.

If you have any further Questions please leave a message.
Keep in mind:- The every solutions posted on Our website is well tested before by our specialist team, But still we do not take any responsibility for any damage it may cause to your cell phone. Use these repairing solutions at your own Risk, Thank you.
